YSR-639 Specification


Processor Municator 2C Chinese CPU 400/800
  • Support 64-bit SysAd
  • Speed = 400-800 Mhz
  • BGA package
    		•
    Flash ROM  2/4Mbit Flash ROM
    Chipsets North bridge : Marvel MV64420-BDM1C133
  • FSB 133MHz
  • DDR166MHz
  • PCI 32-bit 33MHz

    South bridge : VIA VT82C686B
    		•
    VGA ATI Radeon 7000-M
  • 33MHz 32-bit PCI
  • Internalized with 16MB DDR RAM buffers
  • Support VGA port & S-Video output
    		•
    Storage 40G HDD:Easily upgradeable ATA100/66/33 support

    40PIN+PCS 44PIN X 1

    Optional
  • Optical Storage: CD-ROM / DVD-ROM / Combo Drive (DVD-ROM+CD-RW) / DVD+RW / DVD Dual
    		•
    System Memory PC2700 SODIMM slot,
    Support DDR 266 module, 128MB/256MB/512/MB,
    512 MB total memory capacity.


    I/O Interfaces Front Side
  • AC'97 Codec ALC210A (Mic-in, Audio out)
  • USB 2.0 port X 4
  • IrDA X 1
  • Power switch x 1 & Reset switch x 1
  • Indicator for power x 1 & Indicator for IDE x 1

    Rear Side
  • S-Video connector
  • VGA out port
  • RJ-45 LAN port
  • RS-232 DB9 COM port
  • PS/2 port
  • DC-in jack
  • One 4-pin power output-connector (support +12V, +5V output)
  • One IDE device

    Onboard
  • One mini-IDE device
    		•
    Communication Internal LAN: On-board 100M/10Mbp/s Ethernet LAN controller Realtek : 8139D

    WiFi-compliant wireless LAN (IEEE 802.11a/b/g) by USB dongle(Optional)

    Modem (Optional)
    OS support THINIX 3.0 (Based on CSIP RPLinux)
    AC adapter Auto-sensing dual voltage support, AC100-240V
    45W, 2Pin, DC 12V, 5A
    Slots IDE X 1 + mini-IDE X 1 + SO-DIMM Socket X 1
    Dimension(L*W*H) mm 180 X 145 X 37mm
    Weight (kg) 0.65kg
    Regulatory to be Compliance 3C, CB, CE, FCC, TUV, UL, BSMI
    Accessories Packing Accessories
  • Quick Guide
  • Support CD (Driver, Utility, Manual)
  • AC Adapter
  • Power Cord

    Factory Option
  • 802.11b/802.11g WLAN Card
  • Li-Ion battery pack
  • Optical Device: DVD-ROM, Combo Drive(DVD-ROM+CD-RW), DVD Dual (DVD+/-RW), Super Multi (DVD+/-RW+DVD-RAM)
    		•
    * The specification is subject to change without prior notice.
